12V 10A Impulse battery charger CTEK MXS 10

Model number 1042

Nominal alternating current voltage220-240 VAC, 50-60Hz

Charging voltage 13,6V-15-8V

Starting voltage 2,0 V

Charging current 10A maximum

Current, power supply 1,0A_rms (at maximum charging current)

Reverse discharging current (current, which is used to discharge the battery if the charger is not connected to a power supply) less than 1Ah/month

Impulse (charging voltage and current quality is very important. Strong current impulses heats up the battery which reduces the lifetime of the anode. Strong current impulses can damage other equipment which is connected to the battery. „CTEK“ battery chargers ensure very clean and low impulse voltage and current)  % less than 4

Environment temperature from -20⁰C to + 50⁰C, power efficiency at high temperature is reduced automatically

Charger type Eight stage fully automatic cycle

Battery type: all types of 12 V lead-acid batteries (WET (with liquid electrolyte), MF (maintenance-free), Ca/Ca, AGM (absorption), GEL batteries)

Battery capacity 20-300Ah

Insulation class: IP 65 (moisture and dust resistant)
